Compact Horizontal Cartoning Machine

AvailabilityIn Stock
CategoryCartoning Machines
Payment MethodsCash, COD, DirectDebit
Rated 0.0/5 based on 0 customer review
5
0
0%
4
0
0%
3
0
0%
2
0
0%
1
0
0%

Compact Horizontal Cartoning Machine Details

At Stellan Tech Innovations in Ahmedabad, we believe you shouldn't have to choose between performance and space.

That's why we created our Compact Horizontal Cartoning Machines. They are specifically engineered to deliver medium to high-speed production in a footprint that saves you valuable factory space.

Don't let the size fool you—these machines handle precise carton forming, product insertion, and sealing with absolute reliability. Built with robust materials and smart automation, you get a true workhorse that requires low maintenance while consistently delivering high-quality output.

Machine Overview:

The Compact Horizontal Cartoning Machine – Up to 60 CPM, offered by Stellan Tech Innovations Pvt Ltd, is a fully automated, space-saving and efficient cartoner machine designed for manufacturers seeking a high-performance packaging solution with a smaller footprint. Operating in a intermittent horizontal mode, this compact machine ensures precise and reliable packaging while achieving speeds of up to 60 cartons per minute (CPM), making it ideal for small to medium-scale production environments. Despite its compact design, this advanced cartonator machine integrates all essential functions, including product checking, carton pick-up, leaflet pick-up, product insertion, carton closure, and carton discharge, ensuring seamless and error-free operation. This machine provides multiple carton closing options, such as tuck-in or hot-melt glue sealing, provide flexibility for different packaging needs. Equipped with a user-friendly PLC control system and intuitive HMI, the machine enables real-time monitoring, quick adjustments and minimal downtime, ensuring maximum operational efficiency. Its space-efficient structure makes it the perfect choice for manufacturers with limited floor space, offering a cost-effective and high-quality automated cartoning solution without compromising performance. Designed for reliability, efficiency and compliance with industry standards, the Compact Horizontal Cartoning Machine helps manufacturers enhance productivity while optimizing floor space utilization in modern production environments.

Key Features:

  • Fully Automated Operation – Ensures seamless product handling, from carton pick-up to product insertion, leaflet placement, and final sealing, minimizing manual intervention.
  • Compact & Space-Saving Design – Optimized for manufacturers with limited floor space, offering high efficiency
  • Medium-Speed Performance – Achieves up to 60 cartons per minute (CPM), making it ideal for small to medium-scale production.
  • Multiple Carton Closing Options – Supports tuck-in or hot-melt glue sealing, offering flexibility to accommodate different packaging requirements.
  • Integrated Product & Leaflet Checking System – No product, no carton pick-up and no leaflet, no push function, ensuring compliance and minimizing waste.
  • Customizable Carton Size Adjustments – Allows flexibility in handling different carton sizes for various product types.
  • User-Friendly PLC & HMI Control System – Enables real-time monitoring, quick setup and easy adjustments for maximum operational efficiency.
  • Seamless Integration into Production Lines – Easily integrates with existing upstream and downstream equipment, enhancing productivity.
  • Low Maintenance & High Reliability – Built with durable mechanical components for long-lasting performance with minimal downtime.

Optional Features:

  • Hot Melt Glue System with Precision Control – Provides strong and secure carton sealing with precise glue application.
  • Batch Coding & Printing Integration – Enables printing of batch numbers, expiry dates, or serialization codes directly onto cartons.
  • Provision for Bottom Lock / Lock Bottom / Hanger Type Cartons
  • Integrated Leaflet Folding Device
  • Polycarbonate Guard

 Technical Specification:

ModelSTHC-60
Carton SizeAs per sample
Carton TypePre folded Cartons Tuck in / Gluing type / Bottom Lock / Lock Bottom / Hanger Type
ProductBottles / Eyedrops / Blisters / Vials / Tubes / Pouches
PneumaticsJanatics / CKD Make
Vacuum CupFesto Make
Output Speed50 to 60 Cartons / minute
Carton Magazine DeviceMedium Carton Magazine Upto 500 Cartons
GearboxIndexing Gearbox "AARVEE Make"
Main Gear MotorBonvario / Rotomotive Make
Power supply1 Phase, 230 V, 50 Hz
Air Supply14 Kg / cm2
Air Consumption15 CFM at 6 bar
Net Weight1200 Kg
Dimension2300mm X 1200mm X 1500mm (L * W * H)
Carton Paper Thickness250 to 350 GSM
Leaflet Paper Thickness55 to 60 GSM
Optional FeaturesIntegrated Inkjet Printer for Batch/Expiration Dates, Integrated Weighing System for Product Quality Control, Integrated Hot-Melt Dispensing System for the Gluing Type Cartons, Integrated Leaflet Folding Device, Automatic Bottle/Blister/ Leaflet/Pouch Feeder Mechanism
